The popular models are including HCB-0910， HCB-1325， HCB-1608， HCB-2113， HCB-2120 while the hot types are 3´ FT， 4.25´ FT， 5.5´ FT， 7´ FT, and the capacity often chosen by our customers are 30-50t/h, 50-100t/h, 100-200t/h. Tell us your needs such as the capacity and materials, and our technical people will prepare the quotation for you asap.
Price is depending on the capaicty and models, different models will have the various price, but we can promise the 100% factory price and max discount for you.
If you are new in this field, our technical people will provide the most professional solutions for you to choose and decide. Welcome to consult us.
| Model | Movable Cone Diameter(mm) | Cavity Type | Feeding Size(mm) | Discharging Opening Size(mm) | Main Shaft Speed(r/min) | Motor Power(kw) | Capacity(t/h) | Overall Dimension(mm) | |
| Feeding Size(mm) | Opening Size(mm) | ||||||||
| SHQ300 | 910 | Fine Coarse | 83 159 | 102 175 | 9-22 13-38 | 580 | 75 | 48-96 65-168 | 2821 × 1880 × 2164 |
| SHQ400 | 1200 | Fine | 127 | 131 | 9-31 | 485 | 110-160 | 68-192 | 2821 × 1974 × 2651 |
| Medium | 156 | 156 | 13-38 | 105-205 | |||||
| Coarse | 178 | 191 | 19-51 | 146-308 | |||||
| SHQ500 | 1395 | Fine | 155 | 173 | 25-65 | 485 | 220-250 | 180-290 | 3360 × 2650 × 3050 |
| Medium | 188 | 198 | 22-50 | 220-335 | |||||
| Coarse | 230 | 245 | 19-45 | 235-575 | |||||
| SHQ600 | 1650 | Fine | 188 | 209 | 16-38 | 485 | 250-280 | 186-332 | 3911 × 2870 × 3771 |
| Medium | 213 | 241 | 22-51 | 263-422 | |||||
| Coarse | 241 | 268 | 25-64 | 304-640 | |||||
